HYSF 2-8 Core L-angle Connector Specifications

Request a quote for: HYSF 2-8 Core L-angle Connector Specifications

Get your non-binding quote today and see how we can help.

Request a Quote

（Click on the image to enlarge）

HYSF 2-8 core L-angle connector

1. Drawing information

Dimensions in mm (1 mm = 0.03937 inch)
Threads in inches (1 inch = 25.4 mm)

2. Plug Color Configuration

Same as corresponding Miniature Watertight Connectors

3. Main parameters

  • Electrical Rating: 550V @ 10A (2-4 cores); 550V @ 5A (5-8 cores)
  • Insulation Resistance: >200 MΩ
  • Contact Resistance: <0.01 Ω
  • Wet Mate/Unmate Cycles: >500 times
  • Operating Temperature: -60°C ~ +80°C
  • Working Depth: 6000m (60 MPa)

4. Material & Installation Requirements

  • Plug Body: Neoprene
  • Socket Body: 316L Stainless Steel, Titanium Alloy, Sea Copper, Anodized Aluminum, PEEK
  • Cable Body: Polyurethane, Neoprene
  • Needle Core: Copper Gilding
  • Installation Radius: 12.5
  • Surface Finish: Ra1.6

5. Dimension & Thread Specifications

  • Dimension Units: Millimeter (mm)
  • Thread Unit: Inch
  • Mounting Thread: 7/16-20UNF-2A
  • Thread Length: 16mm
  • Customization: Available upon request

Face view

Request 3D STP File
